Ford Mustang bolt pattern, wheel sizes and wheels that fit

Q: What is the Ford Mustang bolt pattern?

It depends on the year: 5x114.3 on 1994–2026, 4x108 on 1979–1993, 4x114.3 on 1972–1973 and 5x114.3 on 1964–1971. Some trims use a different pattern: 5x114.3 (1993, 1984–1986, 1972–1973), 4x114.3 (1971, 1968–1970, 1964–1967) and 5x120.65 (1968–1970). Pick your trim in the visualizer for the exact one.

Ford Mustang wheel fitment: bolt pattern 5x114.3 (1994–2026), 4x108 (1979–1993), 4x114.3 (1972–1973), factory wheel and tire sizes for every year, the aftermarket sizes DriveRight lists as tested, wheels in stock that fit, and 268 real wheel builds on the Mustang.

See wheels on your Mustang

Quick answers

What is the Ford Mustang bolt pattern?

It depends on the year: 5x114.3 on 1994–2026, 4x108 on 1979–1993, 4x114.3 on 1972–1973 and 5x114.3 on 1964–1971. Some trims use a different pattern: 5x114.3 (1993, 1984–1986, 1972–1973), 4x114.3 (1971, 1968–1970, 1964–1967) and 5x120.65 (1968–1970). Pick your trim in the visualizer for the exact one.

What size wheels fit a Ford Mustang?

Factory wheels: 19x9 +45 (2024–2026), 17x7.5 +45 (2022–2023), 19x9 +45 front, 19x9.5 +52 rear (2021) and 19x10.5 +40 front, 19x11 +45 rear (2018–2020). DriveRight's tested aftermarket sizes for the 2026 Mustang: 19 to 20 in, offsets +30 to +45.

What offset fits a Ford Mustang?

On the 2026 Mustang, DriveRight's tested offsets run +30 to +45 depending on width and diameter. Lower offsets push the wheel out toward the fender; the table below lists factory offsets by year.

Years	Bolt pattern	Hub bore	Factory wheel	Factory tire	Lug thread	Tested aftermarket sizes
2024–2026	5x114.3	70.6 mm	19x9 +45	255/40R19	M14x1.5	19 to 20 in, offsets +30 to +45
2022–2023	5x114.3	70.6 mm	17x7.5 +45	235/55R17	M14x1.5	17 to 20 in, offsets +30 to +50
2021	5x114.3	70.6 mm	19x9 +45 front, 19x9.5 +52 rear	255/40R19	M14x1.5	19 to 20 in, offsets +30 to +45
2018–2020	5x114.3	70.6 mm	19x10.5 +40 front, 19x11 +45 rear	295/35R19	M14x1.5	19 to 20 in, offsets +30 to +40
2015–2017	5x114.3	70.6 mm	19x9 +45	255/40R19	M14x1.5	18 to 20 in, offsets +25 to +45
2014	5x114.3	70.6 mm	16x7 +52	215/65R16	1/2 UNF	16 to 22 in, offsets +32 to +50
2008–2013	5x114.3	70.6 mm	18x9.5 +48 front, 18x9.5 +38 rear	255/45R18	1/2 UNF	18 to 22 in, offsets +32 to +45
2005–2007	5x114.3	70.6 mm	16x7 +52	215/65R16	1/2 UNF	16 to 22 in, offsets +32 to +50
1994–2004	5x114.3	70.6 mm	15x6.5 +22	205/65R15	1/2 UNF	15 to 20 in, offsets +15 to +34
1993	4x108 (5x114.3 on some trims)	63.9 mm	13x5.5 +15	245/45R17	1/2 UNF	13 to 150 in, offsets +8 to +25
1987–1992	4x108	63.9 mm	13x5.5 +15	245/45R17	1/2 UNF	13 to 150 in, offsets +8 to +25
1984–1986	4x108 (5x114.3 on some trims)	63.9 mm	13x5.5 +15	245/45R17	1/2 UNF	13 to 150 in, offsets +8 to +25
1979–1983	4x108	63.9 mm	13x5.5 +15	245/45R17	1/2 UNF	13 to 150 in, offsets +8 to +25
1972–1973	4x114.3 (5x114.3 on some trims)	61.9 mm	13x5.5 +18	6.95-14	1/2 UNF	14 to 15 in, offsets -6 to +18
1971	5x114.3 (4x114.3 on some trims)	70.3 mm	13x5.5 +18	6.50-13	1/2 UNF	13 to 18 in, offsets -6 to +30
1968–1970	5x114.3 (4x114.3 / 5x120.65 on some trims)	70.3 mm	13x5.5 +18	6.50-13	1/2 UNF	13 to 18 in, offsets -6 to +30
1965–1967	5x114.3 (4x114.3 on some trims)	70.3 mm	13x5.5 +18	6.50-13	1/2 UNF	13 to 18 in, offsets -6 to +30
1964	5x114.3 (4x114.3 on some trims)	70.3 mm	14x5.5 +18	6.95-14	1/2 UNF	14 to 18 in, offsets -6 to +30
